Liquid sources

#{name}

Our liquid sources are mostly used in laboratories detection metrology purposes: calibration of detectors, periodic quality inspections such as control charts, periodic verification of detection performance.

The associated measurement systems are the devices used to control the discharge of liquid effluents into the environment: gamma spectrometry or liquid scintillation counting.

#{name}

The specific activity of our liquid sources is characterized by means of Nal scintillators, HPGe semi-conductors or liquid scintillation analyzers. They are calibrated under COFRAC* protocols. The measurement uncertainty varies between 1% and 8% depending on the radionuclide and the geometry.

* Scope N°2-6386 available on www.cofrac.fr or upon request.

Activities

The specific activity levels available as catalog reference are:

• 0. 001 μCi/g (0.04 kBq/g)

• 0.01 μCi/g (0.4 kBq/g)

• 1.1 μCi/g (40 kBq/g)

• 21.6 μCi/g (800 kBq/g)

• 261.2 μCi/g (8 000 kBq/g)



Standard geometries

• Ampoules

• V-Vial bottles

• Penicillin bottles

• Standardized bottles

Our liquid sources can be conditioned in other geometries offered in our catalog or provided by the customer.


#{name}
Pack Liquides © LEA
Fabrication ELSB © LEA - Cyril Crespeau
#{name}
ELSA
ELSB
ELSU
ELSV
ELSW
ELSE
ELSF
ELSD
ELSJ
ELSL


Geometries              [Type]

 Ampoules . . . . . A or B

 V-Vial. . . . . . . . . U, V or W

 Pénicillin . . . . . D, J* or L

 SG . . . . . . . . . . . E or F



Activities [Act]

 0.001 µCi/g

• 0.01 µCi/g

1.1 µCi/g

 21.6 µCi/g

 261.2 µCi/g

 Other activities on request

How to compose the reference ?

Replace [Type] and [Act] with the letter and the value

according to the required geometry and activity.

For example, a 5ml ampoule (B type) containing 1.1 μCi/g

(40 kBq/g) of 137Cs is referenced as CS137 ELS B

40kBq/g.



Radionuclide

Chemical form

Carrier

Reference

Note



α

αγ

237Np

HCL 6N ou HNO3 3N

Oxalic acid [33μg/g]

NP237 ELS [Type] [Act]

Available geometries: A, B, U, V, W

Maximum = 40 kBq/g



238Pu

HNO3 3N

-

PU238 ELS [Type] [Act]

Available geometries: A, B, U, V, W

Maximum = 40 kBq/g



239Pu

HNO3 3N

-

PU239 ELS [Type] [Act]

Available geometries: A, B, U, V, W

Maximum = 40 kBq/g



241Am

HNO3 1N

EuCl3 [10μg/g]

AM241 ELS [Type] [Act]

Available geometries: A, B, U, V, W

Maximum = 40 kBq/g



244Cm

HNO3 1N

-

CM244 ELS [Type] [Act]

Available geometries: A, B, U, V, W

Maximum = 40 kBq/g



β

3H

H2O

-

H3 ELS [Type] [Act]

Only available in A and B type

Maximum = 800 kBq/g



14C

H2O

D-glucose [50μg/g] +

formaldehyde [1mg/g]

C14 ELS [Type] [Act]

Maximum = 800 kBq/g



32P

HCL 0,1N

Na2HPO4 [10μg/g]

P32 ELS [Type] [Act]

Maximum = 800 kBq/g



35S

HCL 0,1N

Na2SO4 [10μg/g]

S35 ELS [Type] [Act]

Maximum = 800 kBq/g



36Cl

H2O

NaCl [10μg/g]

CL36 ELS [Type] [Act]

Maximum = 800 kBq/g



45Ca

HCL 0,1N

CaCl2 [10μg/g]

CA45 ELS [Type] [Act]

Maximum = 800 kBq/g



63Ni

HCL 0,1N

NiCl2 [10μg/g]

NI63 ELS [Type] [Act]

Maximum = 800 kBq/g



89Sr

HCL 0,1N

SrCl2 [20μg/g]

SR89 ELS [Type] [Act]

Maximum = 800 kBq/g



90Sr + 90Y

HCL 0,1N

SrCl2 [20μg/g]

+ YCl3 [10μg/g]

SR90 ELS [Type] [Act]




99Tc

H2O

-

TC99 ELS [Type] [Act]

Maximum = 800 kBq/g



147Pm

HCL 0,1N

LaCl3 [10μg/g]

PM147 ELS [Type] [Act]

Maximum = 800 kBq/g



βγ

γ

22Na

HCL 0,1N

NaCl [10μg/g]

NA22 ELS [Type] [Act]

-



51Cr

HCL 0,1N

CrCl3 [60μg/g]

CR51 ELS [Type] [Act]

-



54Mn

HCL 0,1N

MnCl2 [26μg/g]

MN54 ELS [Type] [Act]

-



55Fe

HCL 0,1N

FeCl3 [10μg/g]

FE55 ELS [Type] [Act]

-



57Co

HCL 0,1N

CoCl2 [10μg/g]

CO57 ELS [Type] [Act]

-



59Fe

HCL 1N

FeCl3 [10μg/g]

FE59 ELS [Type] [Act]

-



60Co

HCL 0,1N

CoCl2 [10μg/g]

CO60 ELS [Type] [Act]

-



65Zn

HCL 0,1N

ZnCl2 [55μg/g]

ZN65 ELS [Type] [Act]

-



85Sr

HCL 0,1N

SrCl2 [20μg/g]

SR85 ELS [Type] [Act]

-



88Y

HCL 0,1N

YCl3 [10μg/g]

Y88 ELS [Type] [Act]

-



109Cd

HCL 1N

CdCl2 [10μg/g]

CD109 ELS [Type] [Act]

-



110mAg

NH4OH 0.1N ou 1N

AgCN [10μg/g]

AG110 ELS [Type] [Act]

-



113Sn

HCL 6N

SnCl4 [10μg/g]

SN113 ELS [Type] [Act]

-



125I

H2O

Na2S2O3 [50μg/g]

+ NaI [50μg/g]

I125 ELS [Type] [Act]

-



129I

H2O

Na2S2O3 [50μg/g]

+ NaI [50μg/g]

I129 ELS [Type] [Act]

-



131I

H2O

Na2S2O3 [50μg/g]

+ NaI [50μg/g]

I131 ELS [Type] [Act]

Maximum = 800 kBq/g



133Ba

HCL 1N

BaCl2 [33μg/g]

BA133 ELS [Type] [Act]

-



134Cs

HCL 0,1N

CsCl [10μg/g]

CS134 ELS [Type] [Act]

-



137Cs

HCL 0,1N

CsCl [10μg/g]

CS137 ELS [Type] [Act]

-



139Ce

HCL 0,1N

CeCl3 [10μg/g]

CE139 ELS [Type] [Act]

-



152Eu

HCL 1N

EuCl3 [10μg/g]

EU152 ELS [Type] [Act]

-

Mix γ

12ML01*

HCL 1N

Mix of unit carriers

12ML01 ELS [Type] [Act]

Available:

•0,002 μCi/g

•0,02μCi/g

•1,1 μCi/g

•21,6 μCi/g




Standard manufacturing tolerance : ± 30% • IAEA Category : 5




The 12ML01 mixture – 241Am, 109Cd, 139Ce, 57Co, 60Co, 51Cr, 137Cs, 113Sn, 54Mn, 65Zn, 85Sr, 88Y – generates around 15 peaks over an energy range from 60 keV to 1836 keV. The quantity of each radionuclide is chosen so that the counting rates of the main peak of each radionuclide are the same order of magnitude. Other geometries are available on request.
